ECTC 2020 Outstanding Session Paper

Jaber Derakhshandeh, Giovanni Capuz, Vladimir Cherman, Fumihiro Inoue, Inge De Preter, Lin Hou, Pieter Bex, Carine Gerets, Fabrice Duval, Tomas Webers, Julien Bertheau, Stefan Van Huylenbroeck, Alain Phommahaxay, Ehsan Shafahian, Geert Van der Plas, Eric Beyne, Andy Miller, and Gerald Beyer

  • EPS
    Members: Free
    IEEE Members: $11.00
    Non-members: $15.00
    Pages/Slides: 6
01 Jun 2020

In this paper, spacer bumps concept is introduced to increase the process window for TCB, lower the sensitivity of electrical yield to bump height variation, maintain the gap between two dies and to prevent too much solder deformation for a test vehicle having multi-diameter bumps from 40um down to 5um pitches. Adding spacer bumps improves the electrical yield dramatically to close to 100% and ensures having good solder joint and IMC formation for both face to face N=2 and back to face N=4 stacks.
